The CR160MC mechanically held lighting contactors are designed for control of lighting loads such as tungsten, fluorescent, mercury and sodium, as well as for general non-inductive loads. The silver cadmium oxide main contacts and silver tungsten arcing contacts give the devices capability of handling a wide variety of lighting loads. Built-in clearing interlocks allow control from either momentary or maintained pilot devices. Shallow design enables fit into 6-inch deep wall.
- Wide range of current ratings
Available in 30 to 225 amp ratings in 2- and 3-pole versions.
- Ideal for wall-cavity mounting
The shallow design makes the CR160 contactors particularly adaptable for wall-cavity mounting applications. They can be mounted in enclosures that fit in 6-inch thick walls.
- Fast and easy installation
The contactors are front connected for convenient wiring and are manually operated with a screwdriver or similar tool, which discourages tampering. Direct bus-mounted forms are available to reduce space, mounting and wiring costs.
